Smt Samsung Hanwha Decan L2 Pick And Place Machine
HANWHA COMPONENT PLACER DECAN L2
Include:
-#of Spindles/2 Gantry x 6 Spidles/Head/10轴＊2悬臂:
- Placement Speed/最佳速度:56,000CPH(Option)
-Vision:Flying Vision /相机识别影像系统＊2
Stage Vision(Option)
-Placement Accuracy/贴装精度:±40μm Cpk≥1.0(0402(01005inch)chip)
±30μm Cpk≥1.0(IC,Stage Vision)
-Component Range/贴装范围:0402(01005) ~ □16mm(H10m)
Max, □55mm(H15mm)(Option)
-PCB Size:50 x 40 ~ 510 x 460mm(Standard)
Max. 1200 x 460mm(Option)
-Conveyor Configutations: Standard:1-2-1
Option:1-2-2/2-2-2/2-2-1/1-1-1
Factory Option:Single Conveyor(Jedec Tray 2ea)
-Feeder Capacity :Max/料架最大放置数量. 120 ea (8mm)
-Power/电源：Voltage:3 phase AC200/208/220/240/380/415V±10%
Frepuency:50/60Hz
Power consumption:Max. 5.0kVa
-Air consumption/耗气量:50Nl/min
-Vacum Pump/真空泵: 50Nl/min
-Weight/重量:Abotu 1,800 kg
-External Dimensions(mm)/设备尺寸：1430(L) x 1740(D) x 1485 (H)
HANWHA COMPONENT PLACER DECAN L2
Include:
-#of Spindles/2 Gantry x 6 Spidles/Head/10轴＊2悬臂:
- Placement Speed/最佳速度:56,000CPH(Option)
-Vision:Flying Vision /相机识别影像系统＊2
Stage Vision(Option)
-Placement Accuracy/贴装精度:±40μm Cpk≥1.0(0402(01005inch)chip)
±30μm Cpk≥1.0(IC,Stage Vision)
-Component Range/贴装范围:0402(01005) ~ □16mm(H10m)
Max, □55mm(H15mm)(Option)
-PCB Size:50 x 40 ~ 510 x 460mm(Standard)
Max. 1200 x 460mm(Option)
-Conveyor Configutations: Standard:1-2-1
Option:1-2-2/2-2-2/2-2-1/1-1-1
Factory Option:Single Conveyor(Jedec Tray 2ea)
-Feeder Capacity :Max/料架最大放置数量. 120 ea (8mm)
-Power/电源：Voltage:3 phase AC200/208/220/240/380/415V±10%
Frepuency:50/60Hz
Power consumption:Max. 5.0kVa
-Air consumption/耗气量:50Nl/min
-Vacum Pump/真空泵: 50Nl/min
-Weight/重量:Abotu 1,800 kg
-External Dimensions(mm)/设备尺寸：1430(L) x 1740(D) x 1485 (H)
5.0
Model Number:
471
Shipping:
Ocean freight · Land freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(sets):10(days),>10(sets):To be negotiated(days)
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Spindles
10 Spindles *2 Gantry
Placement Speed
78,000CPH
Placement Accuracy
±40μm@μ±3
Item
Place Machine PNP Machine
Dimension(mm)
1650*1690*1458
Application
SMT PCB Assembly Production Line
Applicable Parts
0402 ~ 14mm
Weight (KG)
1000
Applicable components
0402
Applicable PCB
Max. 510(L) x 460(W)
Warranty of core components
1 Year
Warranty
1 Year
Video outgoing-inspection
Provided
Showroom Location
Egypt
Place of Origin
Guangdong, China
Marketing Type
New Product 2020
Machinery Test Report
Provided
Core Components
PLC
Condition
New
Product Description
• Improves actual productivity
• Improves placement quality
• Reduces loss rate
Highest Performance among Chip Mounters of the Same Class
Highest Applicability of Medium Speed Chip Mounters to PCBs
• 510 x 510mm (standard) / 1500 x 460mm (option)
– Possible to produce PCBs up to 1,500mm(L) x 460mm(W) in size
Expands the Component Recognition Range with a High Pixel Camera
• The fly camera can recognize all chips of 03015 ~ 16mm
Improves Simultaneous Pickup Rate
• Arranges pocket positions automatically through communication between the machine and feeder
Improves the Placement Speed of an Odd-Shape Component
• Increases speed by approximately 25% by optimizing the fix camera recognized motion sequence
Places Microchips Stably
Recognizes the Nozzle Center
• Improves the microchip loss rate and placement quality by preventing the occurrence of air leaks
Run Time Calibration
• Maintains placement accuracy by performing automatic calibration during production
Auto Maintenance Prevents Pickup Error and Maintains Placement Quality*
• Measures pneumatic pressure and flow rate of the nozzle and shaft
• Removes foreign materials on the nozzle and shaft by high pressure
air blast
Increased Convenience of Operation
Reduces the Teaching Time of a Large Odd-shape Component
• Expanded FOV of Fiducial Camera: 7.5mm → 12mm
– Reduces the time to teach the component pickup/placement point and improves the convenience of teaching
Maintains the Pickup Coordinate of the Common Feeder
• When changing a model, reduces the model changing time by succeeding the pickup information of a similar model
Unifies the Chip Component Lighting Level
• By setting the same lighting value collectively, minimizes the lighting changing time, removes the productivity deviation by
machine and improves the convenience of part DB management
Support of Multi-vendor Component *
• It’s possible to manage the same components supplied by two suppliers in one part name, so it’s Possible to perform production
continuously without changing the PCB program for the components supplied by different vendors
Teaches Large-sized Components Easily (Panoramic View)
• Performs split-recognition of a large-sized component that is out of
the camera recognition range (FOV) and merges split component images into a single image before displaying.
– Easily teaches the pickup/placement position of a large-sized component
• Improves placement quality
• Reduces loss rate
Highest Performance among Chip Mounters of the Same Class
Highest Applicability of Medium Speed Chip Mounters to PCBs
• 510 x 510mm (standard) / 1500 x 460mm (option)
– Possible to produce PCBs up to 1,500mm(L) x 460mm(W) in size
Expands the Component Recognition Range with a High Pixel Camera
• The fly camera can recognize all chips of 03015 ~ 16mm
Improves Simultaneous Pickup Rate
• Arranges pocket positions automatically through communication between the machine and feeder
Improves the Placement Speed of an Odd-Shape Component
• Increases speed by approximately 25% by optimizing the fix camera recognized motion sequence
Places Microchips Stably
Recognizes the Nozzle Center
• Improves the microchip loss rate and placement quality by preventing the occurrence of air leaks
Run Time Calibration
• Maintains placement accuracy by performing automatic calibration during production
Auto Maintenance Prevents Pickup Error and Maintains Placement Quality*
• Measures pneumatic pressure and flow rate of the nozzle and shaft
• Removes foreign materials on the nozzle and shaft by high pressure
air blast
Increased Convenience of Operation
Reduces the Teaching Time of a Large Odd-shape Component
• Expanded FOV of Fiducial Camera: 7.5mm → 12mm
– Reduces the time to teach the component pickup/placement point and improves the convenience of teaching
Maintains the Pickup Coordinate of the Common Feeder
• When changing a model, reduces the model changing time by succeeding the pickup information of a similar model
Unifies the Chip Component Lighting Level
• By setting the same lighting value collectively, minimizes the lighting changing time, removes the productivity deviation by
machine and improves the convenience of part DB management
Support of Multi-vendor Component *
• It’s possible to manage the same components supplied by two suppliers in one part name, so it’s Possible to perform production
continuously without changing the PCB program for the components supplied by different vendors
Teaches Large-sized Components Easily (Panoramic View)
• Performs split-recognition of a large-sized component that is out of
the camera recognition range (FOV) and merges split component images into a single image before displaying.
– Easily teaches the pickup/placement position of a large-sized component
Specification
item | hanwha S1 |
Number of shaft rod | 10 shaft rod X1 cantilever |
mount speed | 47000 |
Packing accuracy | ± 28m@Cpk ≥ 1.0/ ChIP |
component size | 03015~55mm(H15),L75mm |
substrate size | L510XW510 (Standard)L1, 500 xw460 (Max) |
Feeder carrying quantity (8mm base) | 120EA |
the energy consumption | Power consumption AC200/208/220/240/380/415 v (50/60 hz, 3 phase) to 3.5 KVA |
PCB thickness | 0.38-4.2mm |
weight (kg) | 1600 |
machine size (mm) | 1430x1740x1485 |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
FAQ
Q: What's your main service? A: We provide total SMT machines and soluton service, professional technology support and after
sales.
Q: Are you a trade company or a manufacture?
A: We are an experienced manufacturer of SMT and PCBA equipment, OEM & ODM service are available.
Q: What is your delivery date?
A: The delivery date is about 35 days after receipt of payment.
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.
Q: Can you provide a whole line solution?
A: Yes, We can supply SMT line, Coating line, DIP line and LED production line.
sales.
Q: Are you a trade company or a manufacture?
A: We are an experienced manufacturer of SMT and PCBA equipment, OEM & ODM service are available.
Q: What is your delivery date?
A: The delivery date is about 35 days after receipt of payment.
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.
Q: Can you provide a whole line solution?
A: Yes, We can supply SMT line, Coating line, DIP line and LED production line.
