PCBA Production Smt Mounter by YFX Machine
Product details of the smt mounter
Product Description
YFX Machine smt mounter is known for its style, selection, and value. . With the raw material and latest technology, our smt mounter is worth your recommendation. We have been able to deliver products on the client side through our efficient transportation facilities within the stipulated time.
| Type | Item | Parameter |
| Operation interface | operating system | Windows XP Operation interface |
| Signal link | SMEMA signal connection | |
| visual system | visual parameters | Upper and lower dual-view high-performance CCD and image processing system. |
| Printing accuracy | Repeat printing accuracy | ±0.01 |
| Printing accuracy | ±0.025 | |
| Cycle time | printing cycle | <8sOne piece does not include print cleaning time |
| PCB parameter | Steel mesh size | 370*370-737*737mm |
| Screen frame fixed | Cylinder | |
| PCB size | Minimum 50*50, Maximum 400*340mm | |
| PCB thickness | 0.4-6mm | |
| PCB weight | ≤3kg | |
| Support method | Magnetic ejector pin, magnetic ejector pin, manual crimping | |
| delivery system | One-stage conveyor system。 | |
| Transmission direction | Left-right, right-left, left-left, right-right, (software control) | |
| UVW platform adjustment range | Not lower than X: ±3mm, Y±7mm.e; ±2 degrees | |
| Platform/Transport Parameters | PCB Transmission height | 900±40mm |
| Platform adjustment angle | Z:±2 degree | |
| Scraper speed | ||
| Printing parameters | Squeegee pressure | 0.5-10kg |
| demoulding speed | 0-20mm/s adjustable | |
| scraper angle | Standard 60 degrees | |
| Wipe the net way | Free combination of dry/wet modes | |
| Whole system | software | Free lifetime maintenance and free lifetime upgrades |
| Gas source | 4-6kgf/cm2 | |
| main power supply | AC:220±10%,50/60HZ 1Φ 1.5KW | |
| physical dimension | 1120*1320*1510 | |
