Standardsmt Mounter PCA Production Provided 10 Spindles *2 Gantry

Company Advantages

· YFX Machine smt mounter is manufactured under the guidance of skilled professionals using optimum grade materials.

· Comprehensive quality control is carried out to ensure that the product meets all relevant quality standards.

· With superior craftsmanship, YFX Machine ensures the quality of smt mounter.

Product Description

• Improves actual productivity
• Improves placement quality
• Reduces loss rate
Highest Performance among Chip Mounters of the Same Class
Highest Applicability of Medium Speed Chip Mounters to PCBs
• 510 x 510mm (standard) / 1500 x 460mm (option)
– Possible to produce PCBs up to 1,500mm(L) x 460mm(W) in size
Expands the Component Recognition Range with a High Pixel Camera
• The fly camera can recognize all chips of 03015 ~  16mm
Improves Simultaneous Pickup Rate
• Arranges pocket positions automatically through communication between the machine and feeder
Improves the Placement Speed of an Odd-Shape Component
• Increases speed by approximately 25% by optimizing the fix camera recognized motion sequence
Places Microchips Stably
Recognizes the Nozzle Center
• Improves the microchip loss rate and placement quality by preventing the occurrence of air leaks
Run Time Calibration
• Maintains placement accuracy by performing automatic calibration during production
Auto Maintenance Prevents Pickup Error and Maintains Placement Quality*
• Measures pneumatic pressure and flow rate of the nozzle and shaft
• Removes foreign materials on the nozzle and shaft by high pressure
air blast
Increased Convenience of Operation
Reduces the Teaching Time of a Large Odd-shape Component
• Expanded FOV of Fiducial Camera: 7.5mm → 12mm
– Reduces the time to teach the component pickup/placement point and improves the convenience of teaching
Maintains the Pickup Coordinate of the Common Feeder
• When changing a model, reduces the model changing time by succeeding the pickup information of a similar model
Unifies the Chip Component Lighting Level
• By setting the same lighting value collectively, minimizes the lighting changing time, removes the productivity deviation by
machine and improves the convenience of part DB management
Support of Multi-vendor Component *
• It’s possible to manage the same components supplied by two suppliers in one part name, so it’s Possible to perform production
continuously without changing the PCB program for the components supplied by different vendors
Teaches Large-sized Components Easily (Panoramic View)
• Performs split-recognition of a large-sized component that is out of
the camera recognition range (FOV) and merges split component images into a single image before displaying.
– Easily teaches the pickup/placement position of a large-sized component

Specification

item	hanwha S1
Number of shaft rod	10 shaft rod X1 cantilever
mount speed	47000
Packing accuracy	± 28m@Cpk ≥ 1.0/ ChIP
component size	03015~55mm(H15),L75mm
substrate size	L510XW510 (Standard)L1, 500 xw460 (Max)
Feeder carrying quantity (8mm base)	120EA
the energy consumption	Power consumption AC200/208/220/240/380/415 v (50/60 hz, 3 phase) to 3.5 KVA
PCB thickness	0.38-4.2mm
weight (kg)	1600
machine size (mm)	1430x1740x1485
