Fine Quality Smt X Ray Machine Smt X Ray Machine Company
Product details of the smt x ray machine
Product Specification
Applicable Parts: 0402 ~ 14mm
Condition: New
Placement Accuracy: ±40μm@μ±3
Warranty of core components: 1 Year
Placement Speed: 78,000CPH
Product Overview
YFX Machine smt x ray machine is available in a variety of design styles and specifications. The performance of this product is more stable than other products on the market. As one of the leading smt x ray machine supplier, YFX Machine supplies the best smt x ray machine for customers.
Product Information
smt x ray machine produced by YFX are of excellent quality and the specific details are as follows.
• Improves placement quality
• Reduces loss rate
Highest Performance among Chip Mounters of the Same Class
Highest Applicability of Medium Speed Chip Mounters to PCBs
• 510 x 510mm (standard) / 1500 x 460mm (option)
– Possible to produce PCBs up to 1,500mm(L) x 460mm(W) in size
Expands the Component Recognition Range with a High Pixel Camera
• The fly camera can recognize all chips of 03015 ~ 16mm
Improves Simultaneous Pickup Rate
• Arranges pocket positions automatically through communication between the machine and feeder
Improves the Placement Speed of an Odd-Shape Component
• Increases speed by approximately 25% by optimizing the fix camera recognized motion sequence
Places Microchips Stably
Recognizes the Nozzle Center
• Improves the microchip loss rate and placement quality by preventing the occurrence of air leaks
Run Time Calibration
• Maintains placement accuracy by performing automatic calibration during production
Auto Maintenance Prevents Pickup Error and Maintains Placement Quality*
• Measures pneumatic pressure and flow rate of the nozzle and shaft
• Removes foreign materials on the nozzle and shaft by high pressure
air blast
Increased Convenience of Operation
Reduces the Teaching Time of a Large Odd-shape Component
• Expanded FOV of Fiducial Camera: 7.5mm → 12mm
– Reduces the time to teach the component pickup/placement point and improves the convenience of teaching
Maintains the Pickup Coordinate of the Common Feeder
• When changing a model, reduces the model changing time by succeeding the pickup information of a similar model
Unifies the Chip Component Lighting Level
• By setting the same lighting value collectively, minimizes the lighting changing time, removes the productivity deviation by
machine and improves the convenience of part DB management
Support of Multi-vendor Component *
• It’s possible to manage the same components supplied by two suppliers in one part name, so it’s Possible to perform production
continuously without changing the PCB program for the components supplied by different vendors
Teaches Large-sized Components Easily (Panoramic View)
• Performs split-recognition of a large-sized component that is out of
the camera recognition range (FOV) and merges split component images into a single image before displaying.
– Easily teaches the pickup/placement position of a large-sized component
item | hanwha S1 |
Number of shaft rod | 10 shaft rod X1 cantilever |
mount speed | 47000 |
Packing accuracy | ± 28m@Cpk ≥ 1.0/ ChIP |
component size | 03015~55mm(H15),L75mm |
substrate size | L510XW510 (Standard)L1, 500 xw460 (Max) |
Feeder carrying quantity (8mm base) | 120EA |
the energy consumption | Power consumption AC200/208/220/240/380/415 v (50/60 hz, 3 phase) to 3.5 KVA |
PCB thickness | 0.38-4.2mm |
weight (kg) | 1600 |
machine size (mm) | 1430x1740x1485 |
sales.
Q: Are you a trade company or a manufacture?
A: We are an experienced manufacturer of SMT and PCBA equipment, OEM & ODM service are available.
Q: What is your delivery date?
A: The delivery date is about 35 days after receipt of payment.
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.
Q: Can you provide a whole line solution?
A: Yes, We can supply SMT line, Coating line, DIP line and LED production line.
