Product details of the small pick and place machine
Product Specification
Product name: Automatic SMD Capacitor Placement Machine
Condition: Used, 100% Original
Function: PCB Prototype Smt Production Line
Delivery: Within 7 Days
Application: SMT PCB Assembly Production Line
Product Description
The newly launched products by Shenzhen Yufuxin Technology Co., Ltd. were all completed by the internationally renowned design company. Through the whole process of strict quality inspection, we ensure product quality to meet industry standards. Shenzhen Yufuxin Technology Co., Ltd. produces on the basis of in-depth understanding of customer needs.
Factory direct sale desktop smt pick and place machine placement machine CM602
![High speed SMT PanasonicNPM-D3/CM-602 pick and place machine for SMT production line PCB assembly line]()
![High speed SMT PanasonicNPM-D3/CM-602 pick and place machine for SMT production line PCB assembly line]()
![High speed SMT PanasonicNPM-D3/CM-602 pick and place machine for SMT production line PCB assembly line]()
Product Description
|
model
|
Panasonic placement machine CM602, CM602-L high speed module placement machine NM-EJM8A
|
|
Substrate size
|
L 50 mm × W 50 mm ~ L 510 mm × W 460 mm
|
|
High-speed placement head
|
12 nozzles
|
|
Mounting speed
|
100 000 cph (0.036 s/chip)
|
|
Placement accuracy
|
±40 μm/chip (Cpk -1)
|
|
Component size
|
0402 chip *5 ~ L 12 mm × W 12 mm × T 6.5 mm
|
|
Substrate replacement time
|
m0.9 s (under the best conditions for a substrate length of 240 mm or less)
|
|
power supply
|
Three-phase AC 200, 220, 380, 400, 420, 480 V, 4.0 kVA
|
|
Air pressure source
|
1m0.49 MPa , 170 L /min(A.N.R.)
|
|
Equipment size
|
W 2 350 mm × D 2 290 mm *2 × H 1 430 mm *3
|
|
weight
|
3 400 kg
|
Machine Features:
1. The XY axis adopts the latest linear motor, which provides the strongest power for the CM602.
2. The new design and materials of the sports arm beam and head not only reduce the weight, but also greatly strengthen the rigidity, making it more stable during the movement
3. The movement of X Y axis adopts high speed and low vibration design.
4. The linear motor adopts a new cooling design scheme, which can cool faster and more effectively than other equipment using linear motors under high-speed movement, ensuring the operating efficiency of the motor and improving its life.
5 or 7 kinds of material racks can correspond to all taping packaging components from 8mm to 104mm, which is the most versatile and applicable equipment in the industry. And according to customer needs, a new 8mm single material rack has been added.
6. The rack exchange during operation, the overall exchange trolley design, the overall exchange support pin design, etc. can greatly improve equipment operation efficiency and model switching time.
7. While improving production efficiency, the mature design of CM402 is used in software, hardware and operation to ensure the interchangeability with CM402.
